LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah
  • LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah
  • LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah
  • LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah
LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26AhLiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26AhLiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah

LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah

    Model Number: GS-IFR3.2V

    Product Name: LiFePO4 Rechargeable Prismatic Battery 3.2V 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah

    Place of Origin: Guangdong, China (Mainland)

    Brand Name: Godson or OEM

    Type: LiFePO4

    Nominal Voltage: 3.2V

    Capacity (Customize): 21Ah-22Ah, 24Ah-25Ah, 25Ah-26Ah



Rated voltage: 3.2 V

Discharge current: 78A

Charge current: 10A (up to 1C 10A)

Resistance: Around 2 mΩ

Maximum charge voltage: (3.6 + -0.05 V)

Continuous Discharge Current: 78A (3C)

Maximum discharge current: 125A (5C)

Minimum discharge voltage: 2.2 V

Weight: 0.653KG

Size: 180 mm (height / with screws) x70 mm (width) x26 mm (thickness)

Application: EV, Power tools, E-bike, Electric motorcycle, Golf car cart,  Tourist coaches,  LED flashlight, Portable power system, etc.


Performance Curves of LiFePO4 Cell:

1. LiFePO4 Cell Charge Curve (Charge at 0.1C)


2. LiFePO4 Cell Discharge Curve (Discharge at 0.2C )


3. LiFePO4 Cell Charge Efficiency At Different Temperature


4. LiFePO4 Cell Cycle Life Curve


5. LiFePO4  Cell Capacity Change At Smart Floating Charge At 55 degree
